Details
  • Optimized power train for fuel efficiency
  • Standard 4 ft deck extension provides more space for people and materials
  • Standard oscillating axle for enhanced terrainability

Power Source

Batteries

NA

Capacity Fuel Tank

22 gal. / 83.28 L

Engine Type Diesel

Kubota D1305 24.8 hp 18.5 kW

Engine Type Dual Fuel

Kubota WG972 31 hp 23 kW

General

Capacity Hydraulic Reservoir

32 gal. / 121.13 L

Machine Weight

17000 lb / 7711.07 kg

Performance

Drive Speed Platform Elevated

0.50 mph / 0.80 km/h

Drive Speed Platform Lowered

3.50 mph / 5.63 km/h

Gradeability

40 %

Lift Time

59 sec.

Lower Time

55 sec.

Maximum Drive Height

30 ft / 9.14 m

Platform Capacity

1500 lb / 680.39 kg

Platform Capacity Extension

500 lb / 226.80 kg

Turning Radius Outside

19 ft 5 in. / 5.92 m

Dimensional Data

Ground Clearance

1 ft / 0.3 m

Machine Height

10 ft 1 in. / 3.07 m

Machine Height Rails Folded

7 ft 9 in. / 2.36 m

Machine Length

17 ft / 5.18 m

Machine Width

7 ft 7 in. / 2.31 m

Platform Dimension A

6 ft 2 in. / 1.87 m

Platform Dimension B

13 ft / 3.96 m

Platform Extension Length

4 ft / 1.22 m

Platform Height

53 ft / 16.15 m

Platform Height Lowered

7 ft / 2.13 m

Platform Railing Height

3 ft 1 in. / 0.94 m

Tire Size

12 x 16.5 FF

Wheelbase

9 ft 9 in. / 2.97 m

Reach Specifications

Platform Height

53 ft / 16.15 m

530LRT JLG
